UJV 200

Quality: Overwhelming Beauty

The UJV200 features a single high-density, high-resolution print head based on the same "330 Engine" used in our flagship printers. With precise ink control, it delivers smooth portrait images with minimal graininess and uniform solid colors with no streaking.

Precise control of ink droplets as small as 4 pl

Each ink droplet is placed exactly where intended, delivering high-quality images with no visible graininess.

Beautiful solid fills with high-density ink

Three precisely controlled droplet sizes are combined to produce smooth, even solid areas. Larger droplets provide coverage, while smaller dots refine details to create rich gradations and outstanding image quality.

Ease of Use:
Achieve optimal image quality with ease —no expertise required.

DAS has evolved!　DAS2 (Dot Adjustment System 2)

With one-touch automatic adjustment, results are consistent regardless of the operator's skill level.

Faster adjustment
Less media used for adjustment
Works on colored and transparent media

Versatility:
Expand Your Business with Diverse Applications

UV ink does not require a specific surface type and can print on a wide variety of substrates.

Brings designs to life on large signage

Wallpaper

Floor sign

Supports up to 3-layer printing (including white and clear) for high-value, premium output.

Backlit Signage: 3-layer printing: Color / White / Color for consistent color day and night.

Window graphics: 2-layer (Color + White) or 3-layer printing with Clear.

Next-generation UV ink that's even safer for people and the environment

The newly developed ELS ink is free from SVHC ^*1 and CMR ^{*2 *3} substances, and offers approximately 30% less odor than before, making it even easier to use.

*1 Substances of Very High Concern (SVHC), which may pose significant risks to human health and the environment
*2 Substances classified as Carcinogenic, Mutagenic, or Reprotoxic (CMR)
*3 Indicates that as of March, 2026, it is not classified in the CMR category as an ink under the EU-CLP Regulation.

UV-LED printing requires no drying time for quick delivery

UV ink cures and fixes to substrates when exposed to UV light (ultraviolet light). This allows printed substrates to be post-processed immediately after printing, this includes laminating and cutting.

Reliable Productivity even during Peak Season

Simple Design

Single Print Head for Simple Maintenance

Single print head system contributes less cleaning time and adjustment time. The simple design allows you to work quickly and easily.

Wide Open Cover for Easy Access

Up-Facing Control Panel for Easy Operation

Ink Saving Function: Reduce Ink Consumption with Just 2 Clicks

Anyone can easily reduce ink consumption without technical expertise.
This function is available with any substrates and profiles.

High Quality UV-LED Printing Without the High Cost or Complexity

The Mimaki UJV200 Series offers high-quality UV-LED roll-to-roll printing designed to reduce hidden costs and improve productivity. Instant UV curing eliminates waiting times before and after printing, while avoiding the high heat used by latex systems that increases power consumption and limits media compatibility. Beautiful color solids and smooth skin tones. From the VDT and MAPS4, sharper fine lines from new DAS2 system. The UJV200 enables stable multi-layer printing without pullback, excellent abrasion resistance for floor graphics, and supports high-value applications using clear ink. With low-odor, SVHC/CMR-free inks. The UJV200 Series provides a safer work environment and consistent output quality

Instant UV‑LED Curing

Instant UV‑LED curing eliminates drying and curing delays

Heat‑Sensitive Media Compatibility

No high heat required—print on heat‑sensitive materials

Energy‑Efficient Operation

Lower power consumption compared to latex systems

User‑Controlled Ink Optimization

Simple, user‑defined ink reduction capability

Advanced Multi‑Layer & Texture Printing

Supports multi‑layer and textured printing for premium applications

Superior Abrasion Resistance

Excellent abrasion resistance, ideal for floor signs

Safer, Low‑Odor Ink Chemistry

Low‑odor SVHC/CMR‑free inks improve work environment safety

Clear Ink Special Effects

Clear ink enables high‑value gloss and matte effects

Rapid Maintenance Cycles

5× faster cleaning times

Automated Media & Dot Adjustment (DAS2)

Easy, automated, and faster adjustments for DAS2, reducing media waste and operator time

Lamifit™ Technology

Lamifit Technology for silvering free Lamination

Intuitive User Experience

Simplified printer operation

High‑Precision Variable Dot Control

Variable Dot Technology down to 4 picoliters (4pl)

Multi‑Level Ink Reduction Control

Adjustable ink reduction feature with 5 selectable levels

Maximum Media Versatility

High‑value prints on virtually any media

UJV200 BROCHURE

		UJV200-130	UJV200-160
Print head		On-demand piezo print head
Print resolution		Y: 600, 900, 1,200 dpi　X: 600, 1,200 dpi
Head gap		By manual 2 levels (1.5/2.0 mm)
Ink	Type/Color	UV-curable ink ELS-170/ELS-175 1 (C, M, Y, K, W, Cl) UV-curable ink LUS-210 1 (C, M, Y, K, W, Cl)
Ink	Capacity	1L bottle
Maximum print width		1,360mm (53.5")	1,610mm (63.4")
Media	Width	210 - 1,370mm (8.3 - 53.9")	210 - 1,620mm (8.3 - 63.8")
	Roll diameter	φ180 mm (7.1") or less
	Roll weight	25 kg (55.1lb) or less [45 kg (99.2 lb) or less with option *2]
	Core diameter	2 inch / 3 inch
Interface		Ethernet 1000BASE-T / USB2.0
Certifications		VCCI class A, FCC class A, ETL IEC 62368-1, CE Marking (EMC, Low voltage, Machinery directive, and RoHS), CB, Energy Star, RCM, KC
Power supply		Single phase AC100-120V±10% /11A or Single phase AC200-240V±10% /5.5A 50/60±1Hz
Power consumption		1,320W (Maximum), 550W (Average running), 4.5W or less (Standby)
Operational environment		Temperature: 20–30 °C (68–86 °F) Humidity: 35–65% Rh (Non condensing) Recommended temperature: 20–25 °C (68–77 °F) Dust level: General office level
Dimensions (W×D×H)		2,520 x 748 x 1,405 mm (99.2 x 29.4 x 55.3")	2,770 x 748 x 1,405 mm (109.1 x 29.4 x 55.3")
Weight		155 kg (341.7 lb)	160 kg (352.7 lb)

*1 ELS-175 and LUS-210 are an ink sold in specific countries and regions.
*2 With the OPT-J0502 Level Foot attached, supports media up to 45 kg (99.2 lb).

High-Quality Printing Made Easier
Entry-level UV printer: Designed for Expressive Capabilities and Ease of Use

"UJV200 Series" is a Roll to Roll UV inkjet printer which equipped with a single print head of "330 Engine" in our flag-ship printer, enabling even inexperienced operators to produce printed products beautifully, quickly, and easily.

Product outlines

Beautiful printing. Mimaki's flag-ship printer's "330 Engine" a single print head is mounted to achieve high image quality.
Achieve optimal image quality with ease —no expertise required: Significantly enhanced Auto image quality adjustment!
Expand Your Business with Diverse Applications: Large signage, High-value-added designs with up to 3-layer printing, etc.
Next-generation UV ink that's even safer for people and the environment: Approx. 30% less odor than before, SVHC-free, CMR-free
Reliable even during busy periods. Highest practical print speed at entry level: 14.0 m²/h
Simple design that is easy for anyone to use. Easy to work with, easy to check, and easy to maintain.
